Digital Shop manual for the Kobelco SK450-6, SK450LC-6 and SK480LC-6(S), serial LS09-01501 and YS09-01301 onwards. 1,132 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK450-6, SK450LC-6, SK480LC-6, SK480LC-6S |
| Book Code | S5LS0010E |
| Serial Numbers | LS09-01501 and up, YS09-01301 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 1132 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK450(LC)-6 and SK480LC-6(S), S/N LS09-01501 and YS09-01301 and up |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5LS0010E |
The latest of our SK450 and SK480 books, for machines in the LS09 and YS09 series. It covers the 6S as well, and at 1,132 pages it is the biggest Kobelco manual in the store.
SK450-6, SK450LC-6, SK480LC-6 and SK480LC-6S from S/N LS09-01501 and YS09-01301. Sections dated November 2004.
Specs and maintenance, the labour time schedule, test procedures, hydraulic and electrical systems, the Mechatro control system, component systems, full disassembly and assembly, troubleshooting and the engine.
LS06 and YS06 machines use S5LS0006E. LS07 and LS08 use S5LS0009E. It is a big file, so download it on a good connection.
Scanned PDF, 1,132 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
