Digital Shop manual for the later Kobelco SK330-6E, SK330LC-6E and SK330NLC-6E, LC08, LC09, YC08 and YC09 serial series. 1,302 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK330-6E, SK330LC-6E, SK330NLC-6E |
| Book Code | S5LC0009E |
| Serial Numbers | LC08-06201 and up, YC08-03001 and up, LC09-06323 and up, YC09-03088 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 1302 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK330(LC)-6E and SK330NLC-6E, S/N LC08-06201, LC09-06323, YC08-03001 and YC09-03088 and up |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5LC0009E |
The later SK330-6E book. It covers two serial series each for the standard and LC machines, so all the running changes Kobelco made through 2003 are in one place.
SK330-6E, SK330LC-6E and SK330NLC-6E from S/N LC08-06201, LC09-06323, YC08-03001 and YC09-03088. First issued March 2003, revised November 2003.
Specs and maintenance, the labour time schedule, test procedures, hydraulic and electrical systems, the Mechatro control system, component systems, full disassembly and assembly, troubleshooting and the engine, plus attachments.
An LC07 machine needs S5LC0008E. An LC06 needs S5LC0007E.
Scanned PDF, 1,302 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
