Digital Shop manual for the Kobelco SK200SR and SK200SRLC, YB02, YB03, LA02 and LA03 serial series. 994 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK200SR, SK200SRLC |
| Book Code | S5YB0002E |
| Serial Numbers | YB02-01601 and up, YB03-02050 and up, LA02-01201 and up, LA03-01237 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 994 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK200SR (S/N YB02-01601, YB03-02050 and up) and SK200SRLC (S/N LA02-01201, LA03-01237 and up) |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5YB0002E |
The second book for the short-tail 20 tonner. Everything behind the cab is stacked tight, and the manual shows the order to pull parts so you do not strip more than you need.
SK200SR from S/N YB02-01601 and YB03-02050, SK200SRLC from S/N LA02-01201 and LA03-01237. First issued March 2002, revised October 2003.
Specs and maintenance, the labour time schedule, test procedures, hydraulic and electrical systems, the Mechatro control system, component systems, full disassembly and assembly, troubleshooting and the engine, plus air conditioning.
YB01 and LA01 machines use S5YB0001E. YB04 and LA04 use S5YB0003E.
Scanned PDF, 994 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
