Digital Shop manual for the Kobelco SK200SR(-1S) and SK200SRLC(-1S) from serial YB04-02301 and LA04-01501. 980 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK200SR, SK200SR-1S, SK200SRLC, SK200SRLC-1S |
| Book Code | S5YB0003E |
| Serial Numbers | YB04-02301 and up, LA04-01501 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 980 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK200SR(-1S) and SK200SRLC(-1S), S/N YB04-02301 and LA04-01501 and up |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5YB0003E |
The latest of our three SK200SR books, including the 1S versions. Kobelco changed enough between editions that the wrong one will have you looking for parts that are not there.
SK200SR, SK200SR-1S, SK200SRLC and SK200SRLC-1S from S/N YB04-02301 and LA04-01501. Sections dated October 2004.
Specs and maintenance, the labour time schedule, test procedures, hydraulic and electrical systems, the Mechatro control system, component systems, full disassembly and assembly, troubleshooting and the engine.
Serials starting YB01 to YB03 or LA01 to LA03 need one of the two earlier books.
Scanned PDF, 980 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
