Digital Shop manual for the Kobelco SK15MSR and SK16MSR minimum swing radius mini excavators, serial PF02-02001 and up. 616 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK15MSR, SK16MSR |
| Book Code | S5PF0002E |
| Serial Numbers | PF02-02001 and up (both models) |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 616 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK15MSR and SK16MSR, S/N PF02-02001 and up |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5PF0002E |
One book for both MSR minis, the machines Kobelco built to slew inside tight spaces. If you service or repair either model, this is the factory reference.
SK15MSR and SK16MSR from S/N PF02-02001. First edition July 2000, revised July 2001.
Specs, maintenance standards and test procedures, hydraulic and electrical systems, attachments, upper and lower structure, troubleshooting, and step-by-step disassembly and assembly, plus the engine section and standard time table.
Go by the serial plate, not the decal. A plate reading PF03 means an SK16 or SK17, which uses S5PF0004E.
Scanned PDF, 616 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
