Digital Shop manual for the Kobelco SK100, SK120 and SK120LC Mark V from serial YW06501, LP11001 and YP02301. 712 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK100 Mark V, SK120 Mark V, SK120LC Mark V |
| Book Code | S5LP0007E |
| Serial Numbers | YW06501 and up, LP11001 and up, YP02301 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 712 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK100 Mark V (S/N YW06501 and up), SK120 Mark V (LP11001 and up), SK120LC Mark V (YP02301 and up) |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5LP0007E |
The first Mark V edition for the SK100 and SK120. The Mark V brought a different control system, so the earlier manuals are not a substitute.
SK100, SK120 and SK120LC Mark V from S/N YW06501, LP11001 and YP02301. Sections dated April 1994.
Specs and component weights, test procedures, the labour time table, hydraulic, swing, travel, control and electrical systems, troubleshooting, and overhaul of the pump, control valve, motors, swivel joint, cylinders and reduction units, plus the engine and air conditioning.
From YW07901, LP13601 and YP02501, use the later edition S5LP0008E, which also adds the SK100L.
Scanned PDF, 712 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
