Digital Shop manual for the Kobelco SK09SR micro excavator, serial PA02-00101 and up. Includes the 2001 and 2003 revisions. 610 pages.
Subscribe for free access to every manual instead.
| Brand | Kobelco |
|---|---|
| Model | SK09SR |
| Book Code | S5PA0001E |
| Serial Numbers | PA02-00101 and up |
| Engine | See manual |
| Manual Type | Factory shop manual |
| Pages | 610 |
| Format / Language | PDF (scanned) / English |
| Compatibility | Kobelco SK09SR, S/N PA02-00101 and up |
| Format | |
| Delivery | Instant, after checkout |
| Product code | KOBELCO-S5PA0001E |
The SK09SR is the one ton micro digger small enough to pass through a doorway. Machines this size get moved and worked hard, and this factory manual covers everything from the undercarriage to the swing and travel motors.
SK09SR from S/N PA02-00101. First edition April 2000, revised July 2001 and February 2003.
Specs, maintenance standards and test procedures, hydraulic and electrical systems, attachments, upper and lower structure, troubleshooting, and step-by-step disassembly and assembly, plus the engine section and standard time table.
Confirm your serial starts with PA02 and is 00101 or higher.
Scanned PDF, 610 pages, English. Diagrams zoom in clearly, but text search will not work. Download link right after checkout. Independent seller, not affiliated with Kobelco.
