John Deere 13.5L PowerTech Plus OEM Diesel Engine Operator's Manual OMRG36873 (Tier 3/Stage IIIA)

This is the John Deere operator's manual for the 13.5 litre PowerTech Plus OEM diesel engine, Tier 3 and EU Stage IIIA. It is written mainly around the 6135HF485 and also lists the 6135HF475.

These six-cylinder engines (132 x 165 mm bore and stroke) are found in gensets, pumps and industrial machines. The manual tells you which fuel, oil and coolant to use, what the diagnostic codes on the panel mean, and when each service item is due.

What the manual covers

• Engine identification and serial plate
• Fuel, lubricant and coolant specifications
• Starting, break-in, running and stopping
• Instrument panel and diagnostic codes
• Service intervals: oil, filters, belts, coolant, valve clearance
• Troubleshooting
• Engine specifications and dimensions, storage, emissions warranty

Models covered

6135HF485 and 6135HF475 (13.5L PowerTech Plus OEM), EPA Tier 3 / EU Stage IIIA. Issue dated 23 March 2015.

Before you order

• Check the fit. Compare the engine model number on your serial plate with 6135HF485 or 6135HF475.
• Manual type. Operator's manual. It covers running and looking after the machine: controls, daily checks, service intervals, fluids and simple fault finding. It does not cover strip-down or overhaul.
• Format. PDF download, 186 pages, English. Link right after checkout. No printed copy is posted.

We are an independent seller and are not affiliated with or endorsed by John Deere.
